TEMPOFIX 3 with TEMPOFLUX 3 frame systems for direct flush /

• Efficiency and water savings: direct flush reduces the risk of leaks, powerful flush is available instantly, dual flush 3L/6L
• Specifically designed for public and commercial places: space saving, easy to clean, withstands intensive use
• Easy to install: frame system delivered pre-mounted, clip into place assembly
• Hygiene: no cistern: no water stagnation (reduces bacterial development)

TEMPOFIX 3 with TEMPOFLUX 3
Frame system with time flow flush

• Black powder-coated steel frame.
• Frame height can be adjusted from 0 - 200mm (with 1m mark).
• Recessed waterproof housing.
• Ø 32mm flush tube with Ø 55mm connection washer.
• ABS soil pipe with HDPE sleeve connector, Ø 110mm outlet
with waterproof seal, with 2 setting positions.
• Delivered pre-mounted.
• Compatible with solid wall finishes from 10 - 120mm.

Available in 2 versions:
Self-supporting frame system with large feet to fix to load-bearing floors.
Wall-mounted frame system to fix to load-bearing walls.
Fitted with TEMPOFLUX 3 F¾" time flow direct flush valve:
• Satin stainless steel control plate 210 162mm, chrome-plated metal
170 170mm or black tempered glass 205 190mm.
• Control plate is fixed manually via concealed screws.
• Soft-touch operation.
• Dual flush 3L/6L, can be adjusted to 2L/4L or single flush 6L.
• AB anti-blocking system.
• Vacuum breaker inside the housing.
• Integrated stopcock and flow rate adjuster.
• Supply pipe diameter: Ø 20mm minimum internal pipe diameter
is required at all points (connectors included).
• Base flow rate: 1 L/sec at 1 bar dynamic pressure.
• Acoustic level complies with European standard EN 12541 class II.
• Compatible with sea water, rain water and grey water.
• Suitable for people with reduced mobility.
• 30-year warranty.
162 10-120
3/4"
210

CISTERN-LESS
1000-1320 WCs

300-620

TEMPOFIX 3 WC frame system with TEMPOFLUX 3
Satin finish stainless steel control plate Ø 110
564065DE £435.99 564065DE + 763000 180-230 165
Self-supporting model, dual flush 350 157-177
+ 763000 £180.17
564060DE £390.10 170x170 160-220 10-120
Wall-mounted model, dual flush 3/4"
+ 763000 £180.17
Chrome-plated metal control plate
564065DE £435.99
Self-supporting model, dual flush
+ 763040 £256.02
564060DE £390.10
Wall-mounted model, dual flush
+ 763040 £256.02
564065DE £435.99
Self-supporting model, single flush
+ 763041 £232.41 1000-1320
564060DE £390.10
Wall-mounted model, single flush
+ 763041 £232.41
Black glass control plate
564065DE £435.99
Self-supporting model, dual flush 300-620
+ 763030 £451.18
564060DE £390.10
Wall-mounted model, dual flush
+ 763030 £451.18 Ø 110
180-230 157-177
Options: wall fixings, sleeve connector and kit for accessible WCs (see page 233)
564060DE + 763040 350
Cistern-less WCs 219
